| Quantity: | |
|---|---|
Model | DIM-1000 |
Internal Dimension | 1000*1000*1000mm D*W*H |
Overall Dimension | 2800*3500*2000mm D*W*H |
Interior Volume | 1000L |
Blowing Dust | |
Air velocity | 1.5 -8.9m/s |
Concentration of dust | 10.7±7g/ m³ |
Dust particles | ＜ 150μm |
Blowing sand | |
Air velocity | 18.0 -29.0m/s |
Concentration of sand | 0.18+0.2g/m³; 1.1+0.3g/m³; 2.2+0.5g/m³ |
Sand particles | 149μm - 600μm, 600μm - 850μm |
Controller | Programmable color LCD touch screen controller |
Door Lock | Electromagnetic lock |
Testing Platform Diameter | 600mm |
Testing Platform Speed | 1-7 r.p.m |
Dust Detector | Integrated dust detector |
Dust collection and cleaning | Equipped with a vacuum cleaner interface, an electric vibrator is installed on the entire air duct and the wall of the test chamber, which can shake off and disperse the dust absorbed on the wall. |
Exterior Material | A3 Steel Plate with protective coating |
Interior Material | SUS304 stainless steel |
Power Supply | 380V 50Hz |
Maximum Noise | 65 dBA |
Standard | MIL-STD- 810g |
Description
Dust (< 150μm) procedure: This test procedure is performed to assist measure the flexibility of equipage to resist the results of mud that will hinder openings, penetrate into cracks, crevices, bearings, and joints, and to judge the effectiveness of filters.
Sand (150 to 850μm particle size) procedure: The Sand (150 to 850μm particle size) procedure is performed to assist measure the flexibility of equipage to be hold on and operated in processing sand conditions while not degrading performance, effectiveness, responsibility, and maintainability because of abrasion (erosion) or preventive effects of huge, sharp-edged particles.
Features
Temperature
10℃～80℃
Blowing Dust
10.7±7g/ m³
Blowing Sand
0.18+0.2g/m³; 1.1+0.3g/m³; 2.2+0.5g/m³
Large Centrifugal Fan
Wind Speed Control
Dust Concentration Control
Internal illumination in test room
Safety protection system
 |  |
 |
|
