| Quantity: | |
|---|---|
Model | SC-016 | ||
Internal dimensions (mm) | 800*1450*680 | 1000*1600*800 | 1000*2000*900 |
Overall dimensions (mm) | 1400*2500*1720 | 1600*2650*1840 | 1600*3050*1940 |
Temperature range | 10℃ ～90℃ | ||
Humidity range | 30% ~ 98% RH | ||
Temperature tolerance | +/- 2.0 ℃ | ||
Humidity tolerance | +2%，-3% | ||
Salt concentration tolerance | ±1% | ||
Spray deposition | 1～2ml / 80cm2 · h | ||
Controller | Programmable color LCD touch screen controller | ||
Temperature sensor | PT100Ω / MV A-class | ||
Humidity sensor | Dry and wet bulb sensor | ||
Heater | Nichrome heater | ||
Cooling system | Mechanical compression refrigeration system | ||
Refrigerating unit | French TECUMSEH compressor | ||
Humidifier | External isolation, stainless steel surface evaporation humidifier | ||
Air circulation | Centrifugal wind fan | ||
Salt fog collected | Fog collector and fog measure cylinder | ||
salt water filtration | Salt water filter near the suction tubes( Avoid the nozzle blockage) | ||
Salt water preheating | Saturated air barrel | ||
Spraying system | Atomizer tower and Spray nozzles (Fog is more fine and uniform distribution) | ||
Interior /Exterior material | |||
Standard configuration | sample holder / Fog collectors / measure cylinder | ||
safety device | Humidifier dry-combustion protection; over-temperature protection; over-current protection; Refrigerant high-pressure protection; Water shortage protection, Earth leakage protection; | ||
Power Supply | AC 380V 50HZ | ||
Test standard | IEC60068-2-52, IEC61701-2， ASTM G85，ISO 7253 | ||
Description
Cyclic salt spray chamber is different from basic salt spray test chamber.Cyclic corrosion test chamber exposes sample to a series of different environments in repetitive cycles that incorporate temperature , humidity, salt spray and dry. Accelerated corrosion test methods included ASTM B117, ASTM BG85, ISO9227, IEC60068-2-52, iec61701-2, ISO7253 and many others.
SC series corrosion chambers are upgrade to programmable controller and Ethernet access. All models are automated, and can working continuously.various models can meet different test requirements.
Features
Pneumatic open /close lid
Material is Glass fiber reinforced plastics (corrosion resistance, high temperature resistance, aging resistance)
Temperature measure, control and display Unit, temperature from +10℃ to +90℃
Humidity measure, control and display Unit, humidity from 30%RH to +98%RH
Salt fog measure and control, 1 to 2 ml/80cm2.h
Programmable color LCD touch screen controller
Ethernet access & USB(option)
Casters and holders are standard
SO2 gas measure and control(option)
Protection system
Standard and custom.
CE mark, ISO17025 calibration
|  |
 |
|
Model | SC-016 | ||
Internal dimensions (mm) | 800*1450*680 | 1000*1600*800 | 1000*2000*900 |
Overall dimensions (mm) | 1400*2500*1720 | 1600*2650*1840 | 1600*3050*1940 |
Temperature range | 10℃ ～90℃ | ||
Humidity range | 30% ~ 98% RH | ||
Temperature tolerance | +/- 2.0 ℃ | ||
Humidity tolerance | +2%，-3% | ||
Salt concentration tolerance | ±1% | ||
Spray deposition | 1～2ml / 80cm2 · h | ||
Controller | Programmable color LCD touch screen controller | ||
Temperature sensor | PT100Ω / MV A-class | ||
Humidity sensor | Dry and wet bulb sensor | ||
Heater | Nichrome heater | ||
Cooling system | Mechanical compression refrigeration system | ||
Refrigerating unit | French TECUMSEH compressor | ||
Humidifier | External isolation, stainless steel surface evaporation humidifier | ||
Air circulation | Centrifugal wind fan | ||
Salt fog collected | Fog collector and fog measure cylinder | ||
salt water filtration | Salt water filter near the suction tubes( Avoid the nozzle blockage) | ||
Salt water preheating | Saturated air barrel | ||
Spraying system | Atomizer tower and Spray nozzles (Fog is more fine and uniform distribution) | ||
Interior /Exterior material | |||
Standard configuration | sample holder / Fog collectors / measure cylinder | ||
safety device | Humidifier dry-combustion protection; over-temperature protection; over-current protection; Refrigerant high-pressure protection; Water shortage protection, Earth leakage protection; | ||
Power Supply | AC 380V 50HZ | ||
Test standard | IEC60068-2-52, IEC61701-2， ASTM G85，ISO 7253 | ||
Description
Cyclic salt spray chamber is different from basic salt spray test chamber.Cyclic corrosion test chamber exposes sample to a series of different environments in repetitive cycles that incorporate temperature , humidity, salt spray and dry. Accelerated corrosion test methods included ASTM B117, ASTM BG85, ISO9227, IEC60068-2-52, iec61701-2, ISO7253 and many others.
SC series corrosion chambers are upgrade to programmable controller and Ethernet access. All models are automated, and can working continuously.various models can meet different test requirements.
Features
Pneumatic open /close lid
Material is Glass fiber reinforced plastics (corrosion resistance, high temperature resistance, aging resistance)
Temperature measure, control and display Unit, temperature from +10℃ to +90℃
Humidity measure, control and display Unit, humidity from 30%RH to +98%RH
Salt fog measure and control, 1 to 2 ml/80cm2.h
Programmable color LCD touch screen controller
Ethernet access & USB(option)
Casters and holders are standard
SO2 gas measure and control(option)
Protection system
Standard and custom.
CE mark, ISO17025 calibration
 | |
|
|
